91
Parts List
GBF-50 Fryer
1 92825 1 or 2 DRAIN TUBE WELD ASSEMBLY, SHORT (Required ONLY for Banked units)
2 41119 ** HOSE, CORRUGATED, SS, 1/2”I.D. x 24”
3 41081 1 HOSE, CORRUGATED, SS, 1/2”I.D. x 30”
4* 31436 1 NIPPLE, BLACK PIPE, 1/2 X 5”
5* 40296 1 TEE, BLACK PIPE, 1/2”
6 41080 ** HOSE, CORRUGATED, SS, 1/2”I.D. x 20”
7 40807 ** REAR CASTER, 5” SWIVEL, NON‐LOCKING, PLATE MOUNT
8 40700 ** FRONT CASTER, 5” SWIVEL, LOCKING, PLATE MOUNT
9
+
40806 3 FRONT CASTER, 5” RIGID, LOCKING, PLATE MOUNT (Front)
ITEM PART NO. QTY DESCRIPTION
** Qty dependent on banked configuration
+ 2‐Bank configuration ONLY
* Used ONLY on Banked Fryer Systems
7.10 Cabinet Underside - Banked Fryer System
