66
Cleaning
GBF-50 Fryer
1. Remove filter pan from fryer as necessary.
2. Remove and clean the Pan Cover ① and dry thoroughly.
3. Use the provided metal Crumb Shovel to remove as much
of the filter sediment accumulated on the filter media
surface, as possible ... particularly around the edge near the
Hold‐down Frame. This will help prevent the pump from
being clogged by loose sediment falling through the
perforated media support screen ⑤ and entering the filter
system plumbing.
4. Turn the four locking levers ② (attached to pan bottom),
disengage Hold‐down Frame ③ and remove from pan.
5. Grasp one end of the soiled filter media ④ and carefully
remove it from pan. Avoid allowing filter sediment to fall
through the support screen.
6. Use a non‐detergent, biodegradable degreaser solution to
thoroughly clean filter pan ⑥ & hold‐down frame ③.
Rinse thoroughly and dry completely. Flush out filter
sediment that may have fallen through the perforated
screen and be certain to drain all residual water from filter
pan hoses.
6
Wear thermal protection to protect hands from potentially hot parts.
5.02 Cleaning the Filter Pan & Refreshing Filter Media
3
4
1
IMPORTANT!
The perforated, Support Screen ⑤ in the filter pan bottom is NOT
a filter. Suitable filter media (reusable screen
or filter paper) must be used to avoid possible equipment damage. Failure to use proper filter media will void
the factory warranty!
2
5
This section describes the process for cleaning filter pan and refreshing the filter media. The procedure should be
performed regularly as part of your daily routine, and after each Boil‐Out Cleaning Procedure (Section 6.01).
GILES recommends using a non‐toxic, non‐detergent, biodegradable degreaser cleaner, such as SIMPLE GREEN®
Crystal Foaming Spray Cleaner/Degreaser along with hot water, to clean and degrease filter pan and
components.
