GILES GBF-50 - Lower Cabinet - Single Unit (W;Oil Options Fresh Bulk & Waste)

86
Parts List
GBF-50 Fryer
7.08 Lower Cabinet: Single (w/Oil Options, Bulk Fresh & Waste)
1
1
2
3
4
56
7
8
9
Left side ‐ facing unit
5
11
4
Right side ‐ facing unit
Rear
NOTE:
Units can be equipped with any
mix of several different Oil
Plumbing Optional
configurations ... on‐board fresh
supply, bulk fresh supply, bulk
waste handling. Components
will differ depending on actual
configuration. Contact Giles
Tech Services for assistance if
needed.
Banked units will have slightly
different pump & plumbing
configurations. Most all piping
& fittings are common Schedule‐
40, 1/2‐NPT, black pipe
