GILES GBF-50 - Lower Cabinet - Single Unit (W;Oil Options Fresh On-Board & Waste)

84
Parts List
GBF-50 Fryer
7.07 Lower Cabinet: Single (w/Oil Options, On-Board Fresh & Waste)
1
1
2
3
2
4
6
5
Right side ‐ facing unit
Rear
4
7
8
NOTE:
Units can be equipped with any mix of several different
Oil Plumbing Optional configurations ... on‐board fresh
supply, bulk fresh supply, bulk waste handling.
Components will differ depending on actual
configuration. Contact Giles Tech Services for assistance
if needed.
Banked units will have slightly different pump &
plumbing configurations. Most all piping & fittings are
common Schedule‐40, black pipe
