Parts List
GBF-50 Fryer
1 21379 1 CONTROLLER, DUAL TIMER, CC10
2 21190 1
SWITCH, ROCKER, ON‐OFF, 250V, 20A, DPST
3 21052 3, 2 or1 SWITCH, ROCKER ,ON‐OFF‐ON, 250V, 20A, DPDT
4 20398 1
INDICATOR LIGHT, GREEN, 250VAC
5 20399 1 or 3
INDICATOR LIGHT, ORANGE, 250VAC
6 20402 1 or 2
INDICATOR LIGHT, RED, 250VAC
7 66126 1 LABEL, CONTROL PANEL, CC10, GBF
8* 20307 3 or 6 RETAINING CLIP, INDICATOR LIGHT
9
+
20621 0‐1or2 HOLE PLUG, SWITCH CUT‐OUT (Unit without switches installed)
10** 21555 1 SWITCH, PUSHBUTTON, MOMENTARY, 10A (Optional fresh oil supply)
11 21556 1 HOLE PLUG, P.BUTTON SWITCH (Unit without switch installed)
ITEM PART NO. QTY DESCRIPTION
7.02 Control Panel - Single Unit or Main Unit of Banked System
* Not Shown
** Optional ‐ fresh oil supply options installed, plugged w/item #11 if not used.
+
Switch location is plugged on units without basket lift and/or units not containing the Pump.
