Parts List
GBF-50 Fryer
1 45755 1 DIVERTER VALVE, DISCHARGE HOSE, 3‐WAY, 1/2‐NPT
2 40784 1 BALL VALVE, 1/2‐NPT, STAINLESS w/TEFLON SEALS
3 92784 1 DRAIN VALVE HANDLE WELD ASSEMBLY
4 21157 1 DRAIN VALVE LIMIT SWITCH, 15A, 250V
5* 21164 1 TERMINAL BLOCK, POWER DISTRIBUTION (inside service box)
6* 21051 1 GROUND LUG (inside service box)
7
+
92766 1
COVER, ELECTRICAL SERVICE ENTRANCE ‐ if replaced, will require item #8 + new warning
labels 63230 [1] & 65630 [1]
8 65678 1 LABEL, SERVICE ENTRANCE COVER, TOP‐HALF
9 93013 1 DRAIN TUBE WELD ASSEMBLY
10* 41106 1 VALVE, DRAIN, 1‐1/2 NPT X 1‐1/2 TUBE, SS (DRILLED & TAPPED))
11 92627 1 COMPLETE FILTER PAN ASSEMBLY w/COVER
12 41900 1 QUICK‐DISCONNECT FITTING, FEMALE, FILTER PAN CONNECTION
13 41699 1 QUICK‐DISCONNECT FITTING, FEMALE, DISCHARGE HOSE
14 65673 1 LABEL, FRONT BRACE, SINGLE‐MAIN UNIT
15 99014 1 HANDLE, WASTE VALVE, WELD ASSY (Optional, waste oil plumbing)
16 40909 1 or 2
HOSE, CORRUGATED, SS, 1/2‐ NPT X 15”
17 40889 5+
ADAPTOR, 1/2‐COMPRESS TO 1/2‐NPT
18 40296 1
TEE, 1/2 NPT, BLACK PIPE
19 43053 1
STREET ELL, 45‐DEG, 1/2‐NPT, BLACK PIPE
ITEM PART NO. QTY DESCRIPTION
7.03 Lower Cabinet - Single Unit or Main Unit of Banked Fryer System
* Not shown
** Optional, present only on unit with bulk waste oil option installed
+ Only partially shown
NOTE:
The 40889 Adapter (item 17) is
used throughout fryer plumbing systems for connecting hoses with compression fittings to
NPT piping.
