GM Energy V2H Bundle Installation Manual 77
Photos for V2H Bundle
Typical Photo
Reason
Photo Taken
During Install
Main service panel (cover removed, all wiring
terminations visible)
Quality control.
X
Main service panel (cover on, all labeling
legible)
Quality control.
Load center 1 (if applicable, cover removed, all
wiring terminations visible)
If applicable (same reason as MSP).
X
Load center 1 (if applicable, cover on, all
labeling legible)
If applicable (same reason as MSP).
X
Additional load center (if applicable, cover
removed, all wiring terminations visible)
If applicable (same reason as MSP).
X
AC disconnect (if required, cover removed,
fuses legible)
Required if MSP and Hub are not in same space
and accessible.
X
AC Disconnect labeling (if applicable, cover on,
labeling legible)
Verify which equipment AC disconnect is
associated with. (NEC 625.43 Disconnecting
Means)
X
Solar System (if present; include any subarrays)
Conrm array layout.
Consumption CTs (any additional premises CT’s
must be captured)
Verify installation.
X
Verify orientation and wiring.
Production CTs
If required.
X
Hub mounting bracket (attached to wall, with
sample fastener atop)
Record of fastener used.
X
Inverter mounting set screws
Separate photo.
X
Hub (top half, cover removed, top back-up
section with all wiring, terminations, and
breakers visible)
Capture additional CT congurations if
applicable.
Verify Eaton Breaker and backup breaker
torque/phasing.
X
Verify busbar breakers.
Verify ground bonding strap (if installed), and
grounding terminations and torque.
Verify PCB wiring connections.
Verify non-factory wiring workmanship (eld
wiring).
Verify consumption CTs orientation.
Verify conduit entry and wiring workmanship.
