RCS User Manual
49
o Packet arrival minimum: It is the minimum interval of arrival between packets in
one second.
o IP payload bitrate: It is the bitrate of the IP packets payload.
o UDP payload bitrate: It is the bitrate of the UDP packets payload.
o Media loss rate: It is the ratio between the number of uncorrected wrong packets
by the total number of packets received per second.
o Loss IP frame: It is the number of uncorrected wrong packets.
o Corrected IP frames: It is the number of corrected wrong packets.
If T2-MI mode is selected, the All In One window has the following information:
For all the inputs, if the option 902564 is enabled in the RCS and the CI card is placed in the
slot (see section Description of Equipment Components), the screenshots will be shown using
the card, so only the images of the services decoded with the card will be shown.
Bitrate Graph of the
selected PLP
List of transport stream bitrates
T2MI packets bitrate list. The PLPs are labeled with an
eye. If you click on one of them, the eye becomes blue
and that PLP will be monitored. If you click on it again,
the eye becomes black, and the monitoring stops.
You can see all the information of the selected PLP in
the tab “TS Analysis” (see section 3.- TS Analysis)
NOTE: Only one PLP can be monitored for each input. The RCS can monitor
up to 4 PLP simultaneously or up to 8 if you have the 902567 option
