Gsertel RCS 100 User Manual

RCS User Manual
48
When the IP input is selected, the measurements shown in the “All In One” window are the
following:
o Packet arrival maximum: It is the maximum interval of arrival between packets in
one second.
Distribution of transport
services and the bitrate of
each one.
when the T2-MI mode is
on (option 902513), this
feature shows the bitrates
corresponding to the T2-
MI packets.
You can also see a mosaic
with the screenshots of all
the services of the channel
that are refreshed
continually.
Right mouse clicking on a
capture will display the
same submenu as RF input
Charts with the evolution
over time of UDP payload
bitrate measurement, and
maximum and minimum
interval between packets
arrival.
List of IP flow measurements.
Bellow you can see the
parameters of the flow.
List of alarms generated
by the system, grouped by
ID. Clicking on an alarm of
the list, a window with
detailed information will
be open
Warning: The yellow triangle at the top of the window indicates that there
are some channels in the plan in more than one input. These channels will be
locked only in the first input.
Edit button:
Goes to IP
channel plans
feature (see
section 1.3.2.
IP Channel
plans)
