1-9
Figure 1-2 Network diagram for remote scheduled automatic upgrade
FTP Client
FTP Server
User
Telnet
Device
1.1.1.1/24
2.2.2.2/24
Internet
Configuration procedure
1) Configuration on the FTP server (Note that configurations may vary with different types of servers)
z Set the access parameters for the FTP client (including enabling the FTP server function, setting
the FTP username to aaa and password to hello, and setting the user to have access to the
flash:/aaa directory).
<FTP-Server> system-view
[FTP-Server] ftp server enable
[FTP-Server] local-user aaa
[FTP-Server-luser-aaa] password cipher hello
[FTP-Server-luser-aaa] service-type ftp
[FTP-Server-luser-aaa] authorization-attribute work-directory flash:/aaa
z Use text editor on the FTP server to edit batch file auto-update.txt. The following is the content of
the batch file:
return
startup saved-configuration new-config.cfg
boot-loader file soft-version2.bin main
reboot
2) Configuration on Device
# Log in to the FTP server (note that the prompt may vary with servers.)
<Device> ftp 2.2.2.2
Trying 2.2.2.2 ...
Press CTRL+K to abort
Connected to 2.2.2.2.
220 WFTPD 2.0 service (by Texas Imperial Software) ready for new user
User(2.2.2.2:(none)):aaa
331 Give me your password, please
Password:
230 Logged in successfully
[ftp]
# Download file auto-update.txt on the FTP server.
[ftp] ascii
