1-12
To do... Use the command... Remarks
Clear statistics for a specific or
all aggregate interfaces
reset counters interface
[ bridge-aggregation }
[ interface-number ] ]
Available in user view
Ethernet Link Aggregation Configuration Examples
In an aggregation group, only ports that have the same port attributes and class-two configurations (see
the Configuration classes
section) as the reference port (see the Reference port section) can operate
as selected ports. Therefore, you must ensure that all member ports have the same port attributes and
class-two configurations as the reference port. The other settings only need to be configured on the
aggregate interface, not on the member ports.
Static Aggregation Configuration Example
Network requirements
As shown in Figure 1-4:
z Device A and Device B are connected through their respective Layer 2 Ethernet interfaces
GigabitEthernet 1/0/1 through GigabitEthernet 1/0/3.
z Configure a Layer 2 static link aggregation group on Device A and Device B respectively, enable
VLAN 10 at one end of the aggregate link to communicate with VLAN 10 at the other end, and
VLAN 20 at one end to communicate with VLAN 20 at the other end.
Figure 1-4 Network diagram for static aggregation
Configuration procedure
1) Configure Device A
# Create VLAN 10, and assign port GigabitEthernet 1/0/4 to VLAN 10.
