H3C S5120-SI Series Configuration Guide

1-4
[SwitchA-GigabitEthernet1/0/2] quit
# Configure port GigabitEthernet 1/0/1 of Switch A to allow only IP packets with the source MAC
address of 00-01-02-03-04-06 and the source IP address of 192.168.0.1 to pass.
[SwitchA] interface gigabitethernet 1/0/1
[SwitchA-GigabitEthernet1/0/1] user-bind ip-address 192.168.0.1 mac-address 0001-0203-0406
2) Configure Switch B
# Configure the IP addresses of various interfaces (omitted).
# Configure port GigabitEthernet 1/0/2 of Switch B to allow only IP packets with the source MAC
address of 00-01-02-03-04-06 and the source IP address of 192.168.0.1 to pass.
<SwitchB> system-view
[SwitchB] interface gigabitethernet 1/0/2
[SwitchB-GigabitEthernet1/0/2] user-bind ip-address 192.168.0.1 mac-address 0001-0203-0406
[SwitchB-GigabitEthernet1/0/2] quit
# Configure port GigabitEthernet 1/0/1 of Switch B to allow only IP packets with the source MAC
address of 00-01-02-03-04-07 and the source IP address of 192.168.0.2 to pass.
[SwitchB] interface gigabitethernet 1/0/1
[SwitchB-GigabitEthernet1/0/1] user-bind ip-address 192.168.0.2 mac-address 0001-0203-0407
3) Verify the configuration
# On Switch A, static binding entries are configured successfully.
<SwitchA> display user-bind
Total entries found: 2
MAC IP Vlan Port Status
0001-0203-0405 192.168.0.3 N/A GigabitEthernet1/0/2 Static
0001-0203-0406 192.168.0.1 N/A GigabitEthernet1/0/1 Static
# On Switch B, static binding entries are configured successfully.
<SwitchB> display user-bind
Total entries found: 2
MAC IP Vlan Port Status
0001-0203-0406 192.168.0.1 N/A GigabitEthernet1/0/2 Static
0001-0203-0407 192.168.0.2 N/A GigabitEthernet1/0/1 Static
Dynamic Binding Function Configuration Example
Network requirements
As shown in Figure 1-2, Switch A connects to Client A and the DHCP server through ports
GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 respectively. DHCP snooping is enabled on Switch A.
Detailed requirements are as follows:
z Client A (with the MAC address of 00-01-02-03-04-06) obtains an IP address through the DHCP
server.
z On Switch A, create a DHCP snooping entry for Client A.
z On port GigabitEthernet 1/0/1 of Switch A, enable dynamic binding function to prevent attackers
from using forged IP addresses to attack the server.
