H3C S5120-SI Series Configuration Guide

1-6
Actions (in the inbound direction)
Port type
Untagged frame Tagged frame
Actions (in the outbound
direction)
Access
Tag the frame with the
default VLAN tag.
z Receive the frame if its
VLAN ID is the same as
the default VLAN ID.
z Drop the frame if its
VLAN ID is different
from the default VLAN
ID.
Remove the default VLAN
tag and send the frame.
Trunk
z Remove the tag and send
the frame if the frame
carries the default VLAN
tag and the port belongs
to the default VLAN.
z Send the frame without
removing the tag if its
VLAN is carried on the
port but is different from
the default one.
Hybrid
Check whether the
default VLAN is
permitted on the port:
z If yes, tag the frame
with the default
VLAN tag.
z If not, drop the
frame.
z Receive the frame if its
VLAN is carried on the
port.
z Drop the frame if its
VLAN is not carried on
the port.
Send the frame if its VLAN is
carried on the port. The
frame is sent with the VLAN
tag removed or intact
depending on your
configuration with the port
hybrid vlan command. This
is true of the default VLAN.
Assigning an Access Port to a VLAN
You can assign an access port to a VLAN in VLAN view, interface view, or port group view.
1) In VLAN view
Follow these steps to assign one or multiple access ports to a VLAN in VLAN view:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter VLAN view
vlan vlan-id
Required
If the specified VLAN does not exist,
this command creates the VLAN first.
Assign one or a group of
access ports to the current
VLAN
port interface-list
Required
By default, all ports belong to VLAN 1.
In VLAN view to assign a Layer-2 aggregate interface to a VLAN, this command assigns the Layer-2
aggregate interface but not its member ports to the current VLAN.
2) In interface or port group view
