H3C S5120-SI Series Configuration Guide

2-8
# Specify commands of level 2 are available to the user logging in to the AUX user interface.
[Sysname-ui-aux0] user privilege level 2
# Set the baud rate of the Console port to 19200 bps.
[Sysname-ui-aux0] speed 19200
# Set the maximum number of lines the screen can contain to 30.
[Sysname-ui-aux0] screen-length 30
# Set the maximum number of commands the history command buffer can store to 20.
[Sysname-ui-aux0] history-command max-size 20
# Set the timeout time of the AUX user interface to 6 minutes.
[Sysname-ui-aux0] idle-timeout 6
After the above configuration, to ensure a successful login, the console user needs to change the
corresponding configuration of the terminal emulation program running on the PC, to make the
configuration consistent with that on the switch. Refer to Setting Up the Connection to the Console Port
for details.
Console Port Login Configuration with Authentication Mode Being
Password
Configuration Procedure
Follow these steps to perform Console port login configuration (with authentication mode being
password):
To do… Use the command… Remarks
Enter system view
system-view
—
Enter AUX user interface
view
user-interface aux 0 —
Configure to authenticate
users using the local
password
authentication-mode
password
Required
By default, users logging in through the
Console port are not authenticated, while
users logging in through the Telnet need
to pass the password authentication.
Set the local password
set authentication
password { cipher |
simple } password
Required
