MEM The memory mode is the mode used when running the machine and making a part. The
active program is shown in the Program Display Pane. Keys in the memory mode line
reflect different ways of running a part in memory. When the keys to the right are
depressed they will show up highlighted in black on the bottom right of the CRT.
SINGLE
BLOCK When depressed SINGLE BLOCK is highlighted in black and will appear on the bottom of
the CRT. When the machine is in SINGLE BLOCK mode only one block of the program is
executed every time the cycle start button is depressed. Used when first test running a
program or temporarily stopping a program when it is running.
DRY RUN Used to check machine movement without cutting a part. In dry run the machine runs at
one feed rate. With the availability of graphics which show visually what the machine
tool path is this mode is rarely used.
OPTION
STOP When OPTION STOP is depressed program will stop at any M01 which is in the program.
Normally M01s are placed after a tool is run in a program. When a job is being set up the
operator may put machine in op stop mode to check dimensions after every tool has
completed cutting.
BLOCK
DELETE When this button is depressed any block with a slash (/) in it is ignored of skipped.
MDI
DNC (MANUAL DATA INPUT mode) – Usually short programs are written in MDI but are not put
into memory. DNC mode allows large programs to be drip fed from a computer into the
control.
COOLNT Turns coolant on and off manually
ORIENT
SPINDLE Rotates and locks spindle to specific angle. Used when lining up tools where spindle
orientation may be a issue such as boring heads.
ATC FWD Rotates turret to next tool and performs tool change - also used to call up specific tools or
pots. Enter tool number (T1) and press ATC FWD.
ATC REV Rotates turret to previous tool and performs tool change - also used to call up specific
tools or pots. Enter tool number (T1) and press ATC REV.
HAND
JOG Puts machine in jog mode for set ups. Top values (.0001, .001, .01, .1) represent distance
traveled per click of jog handle. Bottom values (.1, 1., 10., 100) represent feed in
inches/minute when jogging axis using jog buttons.
