Haemonetics ACP 215 Service Manual

Preventive Maintenance and Installation 101
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
3. Set the meter switch settings as follows:
 Leakage
 Neutral closed
 Polarity normal
4. Turn on the PCS2.
5. Note the reading in microamperes on the meter.
6. Depress the GND switch on the meter.
7. Change the polarity switch from normal to reverse.
8. Verify the readings comply with the current standard EN60601-1, refer to
the following table for acceptance criteria:
Ground
Continuity
1. Change the meter mode to RESISTANCE.
2. Plug the ground wire (coiled wire with clip) into the grounding socket on
the leakage meter.
3. Attach the clip to the following exposed metal locations. Verify that there
is continuity.
 Rear panel hardware
 Front panel hardware
 Pinch valve plungers
4. Verify the highest reading is less than 0.3 Ohm.
Condition Polarity Ground Limit
Normal Normal Normal < 100 µ amps
Single Fault Normal Open < 500 µ amps
Single Fault Reverse Open < 500 µ amps
Normal Reverse Normal < 100 µ amps
