Calibration and Configuration 121
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
6. Press MODIFY PROGRAM until the arrow points to RS232 Device and
then press START. The following screen is displayed:
7. Press MODIFY PROGRAM until printer is selected, then press START.
The following screen is displayed:
8. Press STOP three times to exit. The following screen appears:
9. Switch the memory protect switch on the CPU board to the Protect On
mode (up) and the following display appears:
10.Press STOP and the device restarts and performs the self test.
Device Data Logging
Note: Data logging, recording of procedures, is not an active option on the
device at this time.
RS232 Device
—> Disk Drive
Printer
Device = XXXXX
RS232 Device
Disk Drive
—> Printer
Device = XXXXX
CONFIGURATION
PROTOCOLS CONFIGURATION
—> LANGUAGE
******************************
** REPLACE MEMORY**
** PROTECTION**
******************************
UTILITIES
CALIBRATION
DIAGNOSTICS
—> CONFIGURATION
MAINTENANCE
