Haemonetics ACP 215 Service Manual

120 Calibration and Configuration
P/N: SM-ACP215-01-EN(AB) Haemonetics
®
ACP-215
®
Service Manual
7. Use MODIFY PROGRAM to move the cursor and YES and NO to select
the digit.
8. Press STOP three times to exit. The following screen appears:
9. Switch the memory protect switch on the CPU board to the Protect On
mode (up) and the following display appears:
10.Press STOP and the device restarts and perform the self test.
RS232 Device (Printer Selection)
Note: In order for the device to send data to the printer, the RS232 device must
be set to “Printer”.
1. Access the Utilities mode of operation by pressing and holding SHAKER
while switching the power on. Hold SHAKER until the UTLITIES menu
appears on the display.
2. Press MODIFY PROGRAM to move the arrow to CONFIGURATION and
then press START.
3. The message REMOVE MEMORY PROTECTION OR STRIKE STOP
appears.
4. Switch the memory protect switch located toward the bottom of the CPU
board (the left-most card cage board, looking from the rear of the unit) to
the Protect Off mode (down). The CALIBRATION screen appears with
three choices: PROTOCOLS CONFIGURATION, LANGUAGE, and
MACHINE.
5. Press MODIFY PROGRAM to move the arrow to MACHINE, then press
START.
CONFIGURATION
PROTOCOLS CONFIGURATION
—> LANGUAGE
******************************
** REPLACE MEMORY**
** PROTECTION**
******************************
UTILITIES
CALIBRATION
DIAGNOSTICS
—> CONFIGURATION
MAINTENANCE
