System Schematics 185
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
Line Sensor Fixture Schematic
Table 10
Connector
P1
Wire reference
Number (Wx)
Wire Color
Pin 4 W3 Green
Pin 5 W1 Black
Pin 8 W2 Red
