Equipment Description 17
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
Specifications
Dimensions
(approximate)
The approximate weight and dimensions for the device are:
Power
Requirements
The power is supplied to the device from an external AC source. The electrical
specifications for operating the device are:
Electrical Voltage: 110 VAC ± 10%. 230 VAC ± 10%
Outlet must be properly grounded.
Operating frequency: 50 – 60 Hz.
Current: 5.0 Amperes Max. at 110VAC
2.5 Amperes Max. at 230 VAC
Standard
Requirements
The device will meet the following standards:
IEC 601-1, IEC 601-1-2, IEC 601-1-4
ASTM D5276 Drop test for loaded containers.
ASTM D-999 Vibration testing for shipping containers.
Characteristics Values
In Operation Closed
Height 26.5 inches (67.5 cm) 17.0 inches (43.0 cm)
Width 21.5 inches (55.0 cm) 21.5 inches (55.0 cm)
Depth 21.5 inches (55.0 cm) 12.0 inches (30.5 cm)
Weight Approximately 56.0 lbs. (25.0 kg)
