122 Calibration and Configuration
P/N: SM-ACP215-01-EN(AB) Haemonetics
®
ACP-215
®
Service Manual
1. Access the Utilities mode of operation by pressing and holding SHAKER
while switching the power on. Hold SHAKER until the UTLITIES menu
appears on the display.
2. Press MODIFY PROGRAM to move the arrow to CONFIGURATION and
then press START.
3. The message REMOVE MEMORY PROTECTION OR STRIKE STOP
appears.
4. Switch the memory protect switch located toward the bottom of the CPU
board (the left-most card cage board, looking from the rear of the unit) to
the Protect Off mode (down). The calibration screen appears with three
choices: PROTOCOLS CONFIGURATION, LANGUAGE, and
MACHINE.
5. Press MODIFY PROGRAM to move the arrow to MACHINE, then press
START.
6. Press MODIFY PROGRAM until the arrow points to Data Logging and
then press START. The following screen is displayed:
7. Press MODIFY PROGRAM to move the arrow to DISABLE then press
START. The following screen is displayed:
8. Press STOP three times. The following screen is displayed:
Data Logging
—> ENABLE
DISABLE
Status = XXXXX
Data Logging
ENABLE
—> DISABLE
Status = XXXXX
CONFIGURATION
PROTOCOLS CONFIGURATION
—> LANGUAGE
******************************
** REPLACE MEMORY**
** PROTECTION**
******************************
