Repair Parts List 177
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
Control panel IF PCB assembly
111434-00
111434-10
Frame, acrylic (shim) 111668-00
Control dist cable assembly 35231-00
Centrifuge assembly (complete)
51104-00
41105-10
Cover switch assembly
39635-00
65393-10
Fluid sensor assembly
37846-00
86473-10
Centrifuge Mtg fluid drain assembly 47109-00
Centrifuge subassembly 48081-00
Motor assembly 38670-00
Top deck assembly 48061-00
Air sensor 35159-01
Air sensor 35159-02
Top deck distr. PCB final assembly
51315-00
55311-10
Pneumatic pinch valve assembly /w 12 inch
cable
50045-01
Pneumatic pinch valve assembly /w 18.5
inch cable
50045-02
Pinch valve assembly (02K085 and newer) 37136-00
Pinch Valve Extension cable (02K085 and
newer)
51342-00
Bl/AC/xfer pump assembly 37607-00
Pump rotor assembly 37606-00
Motor assembly 35367-00
Line sensor assembly
48073-00
73048-10
Line sensor gasket 48074-00
Parts description Non-RoHS Returnable Part No.
