Haemonetics ACP 215 Service Manual

Repair Parts List 179
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
Power supply subassembly 50054-00
Motor control PCB assembly 36823-00
Power supply
50197-00
71509-10
Power supply/AC harness assembly 50060-00
Support Plate assembly 50055-00
Compressor assembly 50441-00
Air tank assembly 38221-00
Air filter 17400-00
Check valve assembly 15464-00
I.V. pole mount assembly 48066-00
Pneumatic manifold assembly 35363-00
I.V. Pole assembly 39289-00
Spring 09206-51
Button top collar 37727-02
Button middle collar 37729-02
Plug lower IV pole 39468-02
Card cage assembly 48221-00
Mother (backplane) PCB assembly
36443-02
36443-10
Main program assembly 49900-00
CPU PCB assembly
39208-02
39208-12
Centrifuge dist. PCB assembly
35215-00
35215-10
Rework driver PCB assembly 50050-00
Driver PCB assembly
36557-04
36557-12
