4 - Sprayer set-up
26
Support leg
÷
NOTE! The strength of the support leg and the jack is designed to support the weight on the hitch tongue, on flat
ground, when the tank is full.
To position the support leg:
1. Remove the pin (1) and pull the shaft (2)
2. Position the support leg with the shaft on the hitch tongue,
replace the pin
3. Turn the handle to lower the support leg to the ground.
4. When the leg is fully supporting the sprayer, you can unhitch the
sprayer from the tractor.
When the sprayer is hitched to the tractor, the leg is positioned on the
support provided for this purpose.
1
2
