8 - Technical specifications
78
Specifications
Pump model 363/10.0
Temperature and pressure ranges
Spraying system:
Hydraulic system:
Hydraulic system working pressure:
Filters and nozzles
Mesh dimensions
Reservoir specifications
Tyre specifications
Working temperature: 2°C to 40°C (36°F to 104°F)
Safety valve tripping pressure: 15 bar (220psi)
Max. discharge valve pressure: 20 bar (290psi)
Max. suction valve pressure: 7 bar (100psi)
Max. working temperature: 75°C (167°F)
Tractor: 210 bar (3,046psi)
min. 160 bar (2,321psi)
30 mesh: 0.58mm
50 mesh: 0.30mm
80 mesh: 0.18mm
100 mesh: 0.15mm
Spraying tank capacity 2,500 litres
Rinsing tank capacity 260 litres
Hand wash tank capacity 20 litres
Tyre dimensions Recommended inflation pressure Min. load index A8/A2
270/95R38 TL 3.6 bar 138A8/138B
270/95R48 TL 3.6 bar 142A8/142B
300/95R46 TL 3.6 bar 146A8/146B
340/85R48 TL 2.4 bar 152A8/149B
420/85R38 TL 4.0 bar 144A8/141B
