Harris DiamondCD Series - 6.2.6 Power Supplies 3.2

6-14 888-2463-001 3/6/08
WARNING: Disconnect primary power prior to servicing.
Diamond Series™
Section 6 Troubleshooting
6.2.6 Power Supplies 3.2
Fault - +32V not present at module (module is the detector). Attached modules will not
have RF output, and will 3-strike and report errors. This fault could also be caused by
power supply over-temperature.
