3-2 888-2463-001 3/6/08
WARNING: Disconnect primary power prior to servicing.
Diamond Series™
Section 3 Operation
3.4 Light Bar
The illuminated light bar above the GUI screen indicates the presence of any summary
fault. The color of the light indicates the overall transmitter operating condition.
• Green - Normal operation, no faults.
• Red - This is a summary fault indication. Referring to the Transmitter Control Screen
will indicate the functional area that generated the fault.
• Yellow - This indicates there is a Control System outage and the transmitter is operat-
ing under the control of the Life Support Board. The information shown on the GUI
is not being updated.
