WARNING: Disconnect primary power prior to servicing.
Section 1 Introduction
Diamond Series™
1.2.1 Diamond Transmitter Models
There are 10 different Diamond Transmitter Models (power levels) available not
including Dual Transmitter configurations. The available models are listed below in
Table 1-1.
Table 1-1 Diamond Transmitter Models and Power Levels
Model # # of PA Modules Peak Power
DHD8P1
4 8 kW
DHD10P1
6 10kW
DHD15P1
8 15 kW
DHD20P1
12 22 kW
DHD30P1
16 31 kW
DHD45P2
24 (12 in each cabinet) 45 kW
DHD60P2
32 (16 in each cabinet) 60 kW
DHD90P3
48 (16 in each cabinet) 88 kW
DHD90P4
48 (12 in each cabinet) 88kW
DHD120P4
64 (16 in each cabinet) 119 kW
DHD150P5
80 (16 in each cabinet) 149 kW
Model nomenclature:
D H D ### P # D
Diamond Digital Peak # of PA Cabinets
High Power Kilowatts DualTran
