3/6/08 888-2463-001 2-27
WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Diamond Series™
2.10.1 Transmitter Control Functions, J1
All control inputs use opto-isolators for surge protection. The opto-isolators can be
powered by an internal +15Vdc which is considered "Half Isolation" or can be powered
by an external customer supplied source from 10 to 24Vdc which is considered "Full
Isolation". Full or half isolation is selected by jumper JP1 on the component side (front)
of the System I/O Board in the rear of the Control Cabinet.
• Half Isolation - JP1 Pins 1-2
• Full Isolation - JP1 pins 2-3
All transmitter control functions are ground switching and require the remote control
equipment to sink at least 15mA to activate the function. The Pinout of J1 is listed in
Table 2-2.
Table 2-2 J1, System I/O Board, Remote Control Connections
Connections Function
J1-1 Transmitter ON
J1-2 Transmitter OFF
J1-3 RF Output Power Raise
J1-4 RF Output Power Lower
J1-5 Select Exciter/Driver "A"
J1-6 Select Exciter/Driver "B"
J1-7 Select Exciter/Driver Auto Switch Mode
J1-8 Select Exciter/Driver Manual Switch Mode
J1-9 Remote Control Failsafe (mutes exciter if open or high)
J1-10 thru J1-18 Spares (non-functional)
J1-19 and J1-37 Remote Vcc - Used for full isolation - To use set JP1 pins 2-3
J1-20 thru J1-35 Grounds (returns for control functions)
