3/6/08 888-2463-001 5-1
WARNING: Disconnect primary power prior to servicing.
Diamond Series™
Section 5
Maintenance and
Alignments
5
5.1 Introduction
This section contains all Maintenance and Alignment procedures for the Diamond
Transmitter. This includes Routine maintenance, PA Module repair, transmitter
calibration, Main Controller and Life Support board hot-swap procedures, Driver setup
and calibration, software updates etc.
!
WARNING:
THE DIAMOND PA MODULES ARE DESIGNED TO HANDLE VERY HIGH TEMPERA-
TURES AND MAY BE EXTREMELY HOT, UP TO 90
O
F (50
O
C) ABOVE ROOM TEM-
PERATURE. DO NOT TOUCH THE MODULES WITH BARE HANDS AFTER THE
TRANSMITTER HAS BEEN RUNNING, ESPECIALLY IN HIGH AMBIENT TEMPERA
-
TURE ENVIRONMENTS. SPECIAL GLOVES HAVE BEEN PROVIDED IN THE REAR
OF THE CONTROL CABINET OR CAN BE OBTAINED FROM HARRIS, PART
#0990006483 OR GRAINGER ITEM #4JF36.
5.2 Routine Mechanical Maintenance
5.2.1 Cleaning
Use a vacuum cleaner as required to clean the cabinets. Be aware of static discharge
problems with the use of high velocity air in dry climates when cleaning any circuit-
board with static sensitive components. A variety of static-safe vacuum equipment is
available at most computer supply dealers.
A soft natural bristled paint brush with metal binding and wood handle can be used to
dislodge dust with minimum static generation. Hold the metal binding and touch a
grounded surface to discharge any difference in potential before working on the board.
Do not use nylon brushes with plastic handles.
