Harris DiamondCD Series User Manual

7-16 888-2463-001 7/08/03
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Diamond Series™
992 9980 001 COMBINER 636-860MHZ HP ASSBLY 1.0 EA A014
Table 7-30 PA MODULE, 600W 736-806MHZ - 992 9898 008
Harris PN Description Qty UM Reference Designators (G)
817 2416 245 PA MODULE SPEC, BAND D, 600W 1.0 EA
943 5494 318 SHIELD, DIVIDER 1.0 EA #A007
992 9898 011 MODULE, BASIC, PA 1.0 EA
992 9971 001 PWA, RF SPLITTER, BAND C/D 1.0 EA A007
992 9973 001 PWA, PALLET, BAND D 6.0 EA A008 A009 A010 A011 A012 A013
992 9973 002 PWA, BAND ’D’ DRIVER PALLET, 1.0 EA A005
992 9976 001 PWA, MODULE CONTROLLER 1.0 EA A001
992 9980 001 COMBINER 636-860MHZ HP ASSBLY 1.0 EA A014
Table 7-31 KIT, SPARE PALLET (636-741MHZ) - 994 9782 002
Harris PN Description Qty UM Reference Designators (B)
252 0465 000 WIRE, RIBBON 5 X 50 MIL 0 FT USED TO SOLDER RF OUT, RF IN
ON A5, A8-A13
404 0899 003 PAD, THERMAL INTERFACE 1.0 EA #A5, #A8-A13
817 2515 032 REPLACE INSTRUCT, PA PALLET 1.0 EA
992 9970 001 PWA, PALLET, BAND ’C’ 1.0 EA USED AS A5, A8-A13
Table 7-32 KIT, SPARE PALLET (736-860MHZ) - 994 9782 003
Harris PN Description Qty UM Reference Designators (C)
252 0465 000 WIRE, RIBBON 5 X 50 MIL 0 FT USED TO SOLDER RF OUT, RF IN
ON A5, A8-A13
404 0899 003 PAD, THERMAL INTERFACE 1.0 EA #A5, #A8-A13
817 2515 032 REPLACE INSTRUCT, PA PALLET 1.0 EA
992 9973 001 PWA, PALLET, BAND D 1.0 EA USED AS A5, A8-A13
Table 7-33 KIT, SPARE PALLET (470-550MHZ) - 994 9782 004
Harris PN Description Qty UM Reference Designators (B)
252 0465 000 WIRE, RIBBON 5 X 50 MIL 0 FT USED TO SOLDER RF OUT, RF IN
ON A5, A8-A13
404 0899 003 PAD, THERMAL INTERFACE 1.0 EA #5, #A8-A13
817 2515 032 REPLACE INSTRUCT, PA PALLET 1.0 EA
992 9975 001 PWA, PALLET, BAND ’A’ 1.0 EA USED AS A5, A8-A13
Table 7-34 KIT, SPARE PALLET (547-638MHZ) - 994 9782 005
Harris PN Description Qty UM Reference Designators (B)
252 0465 000 WIRE, RIBBON 5 X 50 MIL 0 FT USED TO SOLDER RF OUT, RF IN
ON A5, A8-A13
404 0899 003 PAD, THERMAL INTERFACE 1.0 EA #5, #A8-A13
817 2515 032 REPLACE INSTRUCT, PA PALLET 1.0 EA
992 9979 001 PWA, PALLET, BAND ’B’ 1.0 EA USED AS A5, A8-A13
Table 7-35 ASSY, PWR SUPPLY, 240VAC, 5KW - 992 9900 007
Harris PN Description Qty UM Reference Designators (C)
606 0989 000 CIRCUIT BREAKER, 40A 2P 480VAC 1.0 EA CB001
736 0354 000 *PSU, SW, 32VDC 240/480VAC 5KW 1.0 EA PS001
992 9900 011 ASSY, POWER SUPPLY, BASIC 1.0 EA
