Harris DiamondCD Series User Manual

7/08/03 888-2463-001 7-27
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Diamond Series™
618 0389 000 LINE XMISSION 6-1/8 1.0 EA
620 0544 000 CONN, ANCHOR INS 3-1/8; 50 OHM 8.0 EA
620 0586 000 CONN, ANCHOR INS 6-1/8; 50 OHM 5.0 EA
620 0637 000 FLANGE, FXD 3-1/8 CU 24.0 EA
620 0638 000 FLANGE, FXD 6-1/8 10.0 EA
620 0713 000 HARDWARE SET 6-1/8 10.0 EA
620 0908 000 HARDWARE KIT, 3-1/8 21.0 EA
620 1336 000 ELBOW, MITER 90 DEG 6-1/8 3.0 EA
620 1893 000 ELBOW 90 DEG 3-1/8 8.0 EA
843 5510 400 LAYOUT, RF EQUIPMENT, DHD120P4 0.0 EA
994 8442 001 KIT, PROBE (1.50); 6-1/8 LINE 2.0 EA
994 8442 005 KIT, PROBE (1.125); 3-1/8 LINE 4.0 EA
Table 7-48 KIT, RF (DIE), DIAMOND, 4-PA - 943 5510 401
Harris PN Description Qty UM Reference Designators (E)
618 0633 000 XMSN LN 6-1/8 20FT 50 OHM 1.0 EA
618 0635 000 LINE, XMSN 3-1/8" 4.0 EA
620 0543 000 CONN, ANCHOR 3-1/8 8.0 EA
620 0908 000 HARDWARE KIT, 3-1/8 21.0 EA
620 1174 000 ELBOW, 3-1/8 EIA FLANGE 8.0 EA
620 1178 000 ELB, 6-1/8 CHAN 2-48 3.0 EA
620 1209 000 ANCHOR CONN. 5.0 EA
620 1227 000 HARDWARE KIT 6-1/8 EIA 10.0 EA
620 1238 000 FLANGE FIXED 3-1/8 EIA 24.0 EA
620 2589 000 FIXED FLANGE 6-1/8 EIA 10.0 EA
843 5510 400 LAYOUT, RF EQUIPMENT, DHD120P4 0.0 EA
994 8442 001 KIT, PROBE (1.50); 6-1/8 LINE 2.0 EA
994 8442 005 KIT, PROBE (1.125); 3-1/8 LINE 4.0 EA
Table 7-49 KIT, XMTR INSTALL, 4 P.A. CAB - 994 9751 004
Harris PN Description Qty UM Reference Designators (D)
003 4010 045 CU, STRAP .020 X 2" 130.0 FT #GROUND SYSTEM
252 0003 000 WIRE, STRD 20AWG WHT 100.0 FT
253 0059 000 CABLE, 2C 22AWG AUDIO 75.0 FT
354 0005 000 TERM LUG RED SPADE 6 30.0 EA
354 0384 000 CONTACT, PIN 80.0 EA #610-0762-000
354 0385 000 CONTACT, SOCKET 40.0 EA #612-0823-000
356 0089 000 CABLE TIE TY RAP 130.0 EA
358 1024 000 CABLE STRIP MOUNT 35.0 EA
358 1213 000 RETAINER KIT, MALE SCREW 3.0 EA
408 0218 000 SHIELD 37 POSITION 2.0 EA
610 0762 000 PLUG 37 PIN 2.0 EA
612 0823 000 RECP 37 CONT POS 1.0 EA
618 0511 000 COAX CABLE RG-223/U 280.0 FT
620 2174 000 "N" PLUG CRIMP ST 22.0 EA FOR USE WITH RG223
746 0251 000 KEYBOARD, COMPUTER, 104 KEY 1.0 EA
Table 7-50 TRANSMITTER, DHD90P3 - 994 9816 001
Harris PN Description Qty UM Reference Designators (Y)
484 0506 000 FILTER, UHF DTV; (REFLECTIVE) 0.0 EA (1 REQ’D) (USED WHEN VENDOR
PASSIVE POWER IS SPECIFIED)
TO BE ORDERED FROM
SCHEDULE ’A’. LAST TWO DIGITS
