Harris DiamondCD Series User Manual

7/08/03 888-2463-001 7-31
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Diamond Series™
994 9752 005 KIT, 208-240V SPARE PARTS 0.0 EA (OPTION, 1 REQ’D FOR 208-240V
XMTR)
994 9752 006 KIT, 430-480V SPARE PARTS 0.0 EA (OPTION, 1 REQ’D FOR 430-480V
XMTR)
994 9782 002 KIT, SPARE PALLET (636-741MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 636-
741MHZ)
994 9782 003 KIT, SPARE PALLET (736-860MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 736-
860MHZ)
994 9782 004 KIT, SPARE PALLET (470-550MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 470-
550MHZ)
994 9782 005 KIT, SPARE PALLET (547-638MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 547-
638MHZ)
994 9783 018 KIT, (4) MODULE SUPPORT 12.0 EA THESE ITEMS SUPPORT POWER
LEVEL QUANTITES FOR
MODULES AND (1 KIT SUPPORTS
4 MODULES
994 9785 010 EXCITER, CD-1A, 0.0 EA OPTION, ORDER 1 OR 2 EXCITERS
AS REQUIRED. (1APEX W/ 1 CD1A
PERMISSIBLE)
994 9912 001 EXCITER, APEX 0.0 EA OPTION, ORDER 1 OR 2 EXCITERS
AS REQUIRED. (1APEX W/ 1 CD1A
PERMISSIBLE)
Table 7-51 KIT, RF (MYAT), DIAMOND, 3PA - 943 5510 300
Harris PN Description Qty UM Reference Designators (D)
618 0378 000 LINE XMISSION 3-1/8 3.0 EA
618 0626 000 XMSN LINE 4-1/16", 20’ 1.0 EA
620 0544 000 CONN, ANCHOR INS 3-1/8; 50 OHM 9.0 EA
620 0637 000 FLANGE, FXD 3-1/8 CU 18.0 EA
620 0908 000 HARDWARE KIT, 3-1/8 16.0 EA
620 1893 000 ELBOW 90 DEG 3-1/8 6.0 EA
620 2137 000 CONN, 4-1/16" ANCHOR INS 5.0 EA
620 2142 000 ELBOW 4-1/16" 90 DEG 3.0 EA
620 2172 000 HARDWARE SET 4-1/16" 9.0 EA
620 2393 000 FLANGE, 4-1/16 FIXED 8.0 EA
843 5510 300 LAYOUT, RF EQUIPMENT, DHD90P3 0.0 EA
994 8442 005 KIT, PROBE (1.125); 3-1/8 LINE 4.0 EA
Table 7-52 KIT, RF (DIE), DIAMOND, 3-PA - 943 5510 301
Harris PN Description Qty UM Reference Designators (F)
618 0359 000 XMISSION LINE 4-1/16 1.0 EA
618 0635 000 LINE, XMSN 3-1/8" 3.0 EA
620 0543 000 CONN, ANCHOR 3-1/8 9.0 EA
620 0908 000 HARDWARE KIT, 3-1/8 16.0 EA
620 1174 000 ELBOW, 3-1/8 EIA FLANGE 6.0 EA
620 1225 000 HARDWARE KIT 4-1/16 EIA 9.0 EA
620 1238 000 FLANGE FIXED 3-1/8 EIA 18.0 EA
620 2950 000 ADAPTER, DIELECTRIC TO MYAT 1.0 EA
843 5510 300 LAYOUT, RF EQUIPMENT, DHD90P3 0.0 EA
994 8442 005 KIT, PROBE (1.125); 3-1/8 LINE 4.0 EA
DIEDC470-014DIE FLANGE, FIELD, SOFT SOLDER 8.0 EA
DIEDC475-011DIE ANCHOR CONN ASSEMBLY 5.0 EA
DIEDC475-021DIE ELBOW 90 DEG. EQUAL LEG 3.0 EA
