Harris DiamondCD Series User Manual

7-52 888-2463-001 7/08/03
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
Diamond Series™
EXCITER) (TWO REQUIRED "1A8",
"1A9" WITH DUAL EXCITER)
992 9914 004 DRIVER, 736 TO 860 MHZ, DD1 0.0 EA OPTION, THIS FREQUENCY (ONE
REQUIRED "1A8" WITH SINGLE
EXCITER) (TWO REQUIRED "1A8",
"1A9" WITH DUAL EXCITER)
992 9916 001 ASSY, 4 SECTION RF DETECTOR 1.0 EA 1A013 (PA CABINET DEPENDENT
1 REQ’D FOR 1 & 2 PA CABINETS)
992 9980 019 COMBINER, 8 WAY 1.0 EA
994 9746 002 KIT, SINGLE EXCITER 0.0 EA (OPTION, 1 REQ’D WHEN SINGLE
EXCITER IS ORDERED)
994 9749 001 KIT, REAR DOOR AIR 1.0 EA (FAN MOTOR IS VOLTAGE
DEPENDENT, KIT IS USED ON ’PA’
CABINET)
994 9749 002 KIT, EXTERNAL AIR 0.0 EA (OPTION, 1 REQ’D, REPLACES
994-9749-001, KIT IS USED ON ’PA’
CABINET.)
994 9751 001 KIT, XMTR INSTALL, 1 P.A. CAB 0.0 EA (1 REQ’D - ADD AS A LINE ITEM)
(MISC. INSTALLATION
MATERIALS TO INSTALL
TRANSMITTER)
994 9752 005 KIT, 208-240V SPARE PARTS 0.0 EA (OPTION, 1 REQ’D FOR 208-240V
XMTR)
994 9752 006 KIT, 430-480V SPARE PARTS 0.0 EA (OPTION, 1 REQ’D FOR 430-480V
XMTR)
994 9782 002 KIT, SPARE PALLET (636-741MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 636-
741MHZ)
994 9782 003 KIT, SPARE PALLET (736-860MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 736-
860MHZ)
994 9782 004 KIT, SPARE PALLET (470-550MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 470-
550MHZ)
994 9782 005 KIT, SPARE PALLET (547-638MHZ) 0.0 EA (OPTION, 1 REQ’D FOR 547-
638MHZ)
994 9783 002 KIT, (4) BLANK MOD & P.S. 2.0 EA BLANKS TO REPLACE 2A13-2A16,
2A18, 2A22 & SUPPLY AIR
994 9783 004 UPGRADE KIT, (8) MOD & P.S. 0.0 EA TO BE ORDERED FROM
SCHEDULE ’A’ (OPTIONS,
UPGRADE FROM 8 TO 12 OR 8 TO
16 MODULES,
994 9783 018 KIT, (4) MODULE SUPPORT 2.0 EA THESE ITEMS SUPPORT POWER
LEVEL QUANTITES FOR
MODULES AND P.S.
994 9785 010 EXCITER, CD-1A, 0.0 EA OPTION, ORDER 1 OR 2 EXCITERS
AS REQUIRED. (1APEX W/ 1 CD1A
PERMISSIBLE)
994 9912 001 EXCITER, APEX 0.0 EA OPTION, ORDER 1 OR 2 EXCITERS
AS REQUIRED. (1APEX W/ 1 CD1A
PERMISSIBLE)
Table 7-68 UPGRADE KIT, (8) MOD & P.S. - 994 9783 004
Harris PN Description Qty UM Reference Designators (F)
055 0100 005 *THERMAL COMPOUND, 8OZ JAR 1.0 EA USED WITH CIRCULATORS AND
ATTENUATOR
357 0089 001 GUIDE MODULE 16.0 EA
408 0340 000 GASKET, EMI 0.385 X 0.420 1.0 EA (TO SEAL TOP OF HIGHEST 4
MODULE BLANK USED)
