3/6/08 888-2463-001 C-5
WARNING: Disconnect primary power prior to servicing.
Appendix C Pioneer Power Supply
Diamond Series™
PM33215F-8 Instructional Manual, Rev 3, 4/23/2007
3
Table of Contents Page
Section 1 Incoming Inspection 4
Section 2 Installation Cautions 4
Section 3 Environmental 4
Section 4 Installation Procedure 4
Section 5 Description 5
x Series and Parallel Configurations 5
x Working Block Diagram 6
x Theory of Operation 7
Section 6 Specifications 9
Section 7 Outline Drawing and Mounting 11
Section 8 I/O Interface Connections 12
Section 9 Quick Bench Testing 13
Section 10 Replacing AC Input Fuses 16
Section 11 Replacing Fan Assembly 20
Section 12 Ordering Parts for Field Repair 23
Section 13 Return Units to the Factory for Repair or Refurb 24
