EXPLANATION OF THE MAIN PARAMETERS
44
MeaningParameterGroup
Input level 24 VInput level 0 VFunctions
Shunt Shunt turned off Shunt turned on
PkMomMax Peak value mode for PkMax Instantaneous value mode
for PkMax
PkMomMin Peak value mode for PkMin Instantaneous value mode
for PkMin
PkHldMax PkMax memory contents
are updated
PkMax memory contents
are frozen
PkHldMin PkMin memory contents are
updated
PkMin memory contents are
frozen
ParaCod1
ParaCod2
Selecting parameter sets and binary-coded inputs
Parameter set ParaCod2 ParaCod1
1 0 0
2 0 1
3 1 0
4 1 1
