HemoCue 201 DM Reference Manual

165
7.5 Log Input
FIGURE 7-24
When the Log Input button is pressed in the
Stored Data Menu, FIGURE 7-4, data for
reviewing or adding logs to the Analyzer log
list is displayed.
It is possible to enter free text or to choose
log notes from a predefined list.
a) Press the Scroll bar arrows(3) to select
either a log note(2), or the Free Text
option(1).
b) Press the Add button(4)
c) If a log note was selected, it will be added
to the Analyzer Log and FIGURE 7-4 will
be displayed.
If the Free Text option(1) was selected
FIGURE 7-25 will be displayed.
1 Free text option
2 Selected Log Note
3 Scroll bar arrows
4 Add button
FIGURE 7-25
d) Enter a free text notation either directly
on the Display via the Text mode(5) and
Numeric mode(6) buttons, or with the
Barcode Scanner via the Barcode Scanner
button(7).
e) Press the Confirm button(8). FIGURE 7-4
will be displayed.
5 Text mode button
6 Numeric mode button
7 Barcode Scanner button
8 Confirm button
Log Input
AddAdd
Free Te xt
Cleaned Opt. Unit
Free Te xt
Cleaned Cuv. Holder
1
4
3
2
Log Input
123123ABCABC
5
6
7
8
Cleaned Display
