Page 6-48 Work Instruction Wizard
PLT-01067, Version: A.7 July 2017
6.5.6 Seos: Reading a Seos Data Object from a Custom ADF
1. Select the Seos technology type. Click OK.
2. The Work Instruction Wizard opens to allow you to configure the Work Instruction for Prox.
Click Next.
3. Configure Seos Instruction Mode: You can make selections from the following. Click Next.
Field Description
Data Type For this example Custom must be selected.
Instruction Type For this example Read must be selected.
Options Not available with Custom.
ADF Configuration ADF OID: A number (8 byte minimum) used to reference the application
after it is created.
Show OID using ASCII characters: Displays ASCII characters.
Read Configuration Custom Read Key: Specify the Custom Read Key which will be used to
authenticate to the ADF to read the Data Object.
Note: If the desired key is not defined, select <Create New Key> from the
drop-down menu.
Read Key ID: This Read Key is to be referenced in the ADF.
