July 2017 PLT-01067, Version: A.7
Work Instruction Wizard Page 6-7
6.1.2 iCLASS: Custom Encoding
This section covers the Work Instruction wizard for iCLASS, with Custom Encoding.
1. Select the iCLASS technology type, and click OK.
2. The Work Instruction Wizard opens to allow you to configure the Work Instruction for iCLASS.
Click Next.
3. Select Data Format: You can make selections from the following. When complete click Next.
Note: For this example Write/Custom/ASCII Text/Custom_Field configuration is selected.
Field Description
Instruction Type Read, Write, or Roll Card Authentication Key
Data Type For this example Custom must be selected.
Options Not available with Custom
Custom Data Plugin Type: ASCII Text, Hexadecimal Data, Unicode Text, and Integer.
Name: Modify the Name, if needed. Note: Name field constitutes column in Work
Order data view.
