July 2017 PLT-01067, Version: A.7
Reader Configuration Page 8-3
8.1.2 Encoder Info Panel
The Key Management Encoder Info panel displays information about the CP1000 Desktop Encoder
currently connected to the computer.
Field Description
Selected Encoder Displays/selects the current Encoder to configure.
Encoder Engine ID Displays the Engine ID of the current Encoder selected above.
Selected Plugin
Data Mapper: See Section 8.3: Data Mapper for detailed information.
Elite Prep Card: See Section 8.5: Elite Prep Card for detailed information.
Load HID Application Keys: See Section 8.8: Load HID Application Keys for
detailed information.
iCLASS Legacy Config Card: See Section 8.6: Reader Options Config Card for
detailed information.
Reader Options Config Card: See Section 8.7: iCLASS Legacy Config Card
Remaining Credits
Displays the number of available credits.
Note: These credits are loaded on to the iCLASS SE Encoder with the other credits
delivered with the encoder, or ordered from HID.
Credits to Transfer
Designates the number of credits to be loaded onto the configuration card.
Note: This is the number of times that the card can be used in the field to program
a door reader.
Credits on Card
The number of credits that are available (unused) on the card. This number is
displayed after the Config Card process is completed or after a Scan Card for
Credits process.
