July 2017 PLT-01067, Version: A.7
Work Instruction Wizard Page 6-13
6.2.2 MIFARE Classic: Custom Encoding
This section covers the Work Instruction wizard for MIFARE Classic, with Custom Encoding.
1. Select the MIFARE Classic technology type. Click OK.
2. The Work Instruction Wizard opens to allow you to configure the Work Instruction for MIFARE
Classic. Click Next.
3. Select Data Format: You can make selections from the following. When complete, click Next.
Note: For this example a Write/Custom/ASCII Text/Custom_Field configuration s selected.
Field Description
Instruction Type Read, Write, Roll Card Authentication Key, or Roll Card Authentication Key.
Data Type For this example Custom must be selected.
Options Not available with Custom.
Custom Data Plugin Type: ASCII Text, Hexadecimal Data, Unicode Text, or Integer.
Name: Modify the Name, if needed. Note: Name field constitutes column in
Work Order data view.
