Page 6-20 Work Instruction Wizard
PLT-01067, Version: A.7 July 2017
6. Key Selection: Select a key to lock the AppArea after the data is written, and click Next.
7. The wizard is complete. Click Finish.
8. Return to Section 5.5: Create a Work Order, step 5 to save the Work Order.
Field Description
Key Set Key Set: Custom or HID defined key sets may be selected
Change Key Set: Standard (No option).
SO Encryption Key: Key set used to encrypt the SO credential. Standard,
Custom, or HID defined key sets may be selected.
Override default PICC Master Key: Allows you to override the HID
Standard or Elite PICC Master key on a DESFIRE card.
Application Keys
Key Type Displays the Key type.
Crypto Method Triple DES, AES, or 3 Key Triple DES (24 byte keys)
Key Diversifier Algorithm None, NIST SENC HMAC, NXP AV1 1 Key Triple DES, or NXP AV1 2 Key
Triple DES
Auth Key None, NXP Default Transport Key, or HID SO PICC Master Key. Also
custom Auth Key is listed.
