July 2017 PLT-01067, Version: A.7
Work Instruction Wizard Page 6-23
5. Key Selection: Set the Application Key options in accordance with the NXP datasheets, and
click Next. All options can be set from the associated drop-down menu.
Note: Selections must abide by the rules you set up for the card.
Field Description
Application Keys
Key Type Displays the Key type.
Crypto Method Triple DES, AES, or 3 Key Triple DES (24 byte keys)
Key Diversifier
Algorithm
None, NXP AV1 1 Key Triple DES, or NXP AV1 2 Key Triple DES
Auth Key
The key used to authenticate to the key specified by Key Type.
None: To signify the key is not used. None is only valid for optional Keys 1-13.
NXP Default Transport Key: For blank cards, typically NXP Default Transport key
is used.
Custom Keys: Custom Keys will be listed, if they are 16 bytes or larger and have
been loaded to the currently selected encoder using the Key Manager.
If the card contains non-default keys (either loaded at the factory or by 3rd party),
than the proper custom key must be selected that can authenticate for the
specified Key Type.
Change Key
The Change Key is used only if the user desires that the current key be changed
during the encoding operation.
None: To signify the key will not be changed.
NXP Default Transport Key: For blank cards, typically NXP Default Transport key
is used.
Custom Keys: Custom Keys will be listed, if they are 16 bytes or larger and have
been loaded to the currently selected encoder using the Key Manager.
File Keys Note: Keys selected in the following must be configured in the Application Keys section
above
Read Key
Select Read Key number (Range 0-13). Default is 0.
Note: 0 indicates that the Application's Master Key will be used to provide access
to the file.
Write Key
Select Write Key number (Range 0-13). Default is 0.
Note: 0 indicates that the Application's Master Key will be used to provide access
to the file.
Read/Write Key
Select Read/Write Key number (Range 0-13). Default is 0.
Note: 0 indicates that the Application's Master Key will be used to provide access
to the file.
