Setting Input Group
Steps:
1. Click Input Group to enter the MVC Input Group interface.
2. Click to select the group No. from the drop-down menu.
3. Set the Cycle Time (1-65535s) for the current group.
The Cycle Time refers to the dwell time defined for each camera in this group.
Figure 6. 7 Setting Input Group
4. Click the Add Camera key to enter the Add Camera interface:
Figure 6. 8 Adding Camera
5. Select the cameras from the list to be added to the group, and then click Add to add the selected cameras.
6. You can also set or edit the Cycle Time (1-65535s) for cameras here.
7. Click Finish to return to the MVC Input Group interface, where you can view the successfully added cameras
for the current group.
