DS-1100KI Network Keyboard User Manual
98
 The range from the start IP to end IP must be larger than the number of the functional modules.
 When the NAT function of the system is enabled, it is not allowed to operate the batch edit.
Configuring Encoder/Decoder Parameters
Click the button of an encoder/decoder on the MVC List and enter its settings interface.
Figure 6. 5 Configuring Encoder/Decoder Parameters
Configuring Encoder/Decoder Parameters
Please refer to the Chapter 4.1 Encoder Settings~ Chapter 4.2 Decoder Settings for details.
6.1.3 Camera List
Viewing Camera List
Click the Camera tab to view the information of all cameras connected to the current MVC system, including the
camera ID, channel No., IP address and port. The No. is used as CAM number in the Shortcut Operation.
Figure 6. 6 Viewing Camera List

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
