DS-1100KI Network Keyboard User Manual
97
interface.
Figure 6. 3 MVC List
The device types in the MVC system are shown as follows:
M_ENC: Encoding module
M_DEC: Decoding module
M_CODE: Code distribution module
M_CAS_IN: Input cascading module
M_CAS_OUT: Output cascading module
M_INTEL: Intelligent module
M_ALARM: Alarm module
V6_DEC: V6 decoding module
V6_CAS: V6 cascading module
MVC_B10: MVC B10
MVC_B11: MVC B11
MVC_B12: MVC B12
M_DS: Domain system
M_SDS: Sub-domain system
MATRIX ACCESS GATEWAY: Matrix access gateway
Editing Device Parameters in Batch
By clicking the Batch Edit IP button, you can enter the Batch Edit interface to edit the parameters of the
encoding/decoding modules, including the start IP, end IP, port, subnet mask and gateway.
Figure 6. 4 Editing Device Parameters in Batch

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
