DS-1100KI Network Keyboard User Manual
128
Click the icon to edit the video wall / scene No..
Video wall list: It mainly aims at DS-6400HD-T series decoder. The video wall on the list is the one configured well
via client software or network keyboard.
Scene list: It mainly aims at B20/multi-screen controller/64-S decoder. The scene on the list is the one configured
well via client software.
7.2.4 Password Modification
Click Password to enter the following interface.
Figure 7. 31 Password Interface
Old Password: Current login password of operator.
New Password: The modified password.
Confirm: Re-input the modified password.
Click Save to save the new password.
7.2.5 AUX Key Settings
Click the Aux Key on the left navigation bar to enter the Aux Key settings interface:
Figure 7. 32 AUX Key Settings
On this interface, you can set the function of Aux Key 1 / Aux Key 2 to two-way audio, picture capture, or video
wall/scene switch.
7.2.6 FTP Server Settings
The video files or captured pictures can be uploaded to FTP server.
Steps:
7. Click Ftp Setting on the left navigation bar to enter the FTP settings interface.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
