HIKVISION DS-1100KI User Manual

DS-1100KI Network Keyboard User Manual
33
3.4.2 Editing/Deleting Device
Edit Device
On the Device-Device List interface, click of the device from the list to be edited and enter the Device-Edit
Device interface.
Steps:
1. You are allowed to edit the device name, port, user name and password. If the password is not strong
enough, a message box “Risky password” pops up to remind you the password is unsafe.
Figure 3. 19 Device-Edit Device
 Message boxes like “Risky password”, “Weak password”, “Middle password” and “Strong password” pop up
as prompts.
 Device name and password are unable to change in this interface.
2. Click Edit to edit the device information.
The user name and password here refer to that are used for logging in the device from keyboard.
Figure 3. 20 Device-Edit Device
Delete Device
On the Device-Device List interface, select the device from the list to be deleted, and click to delete it. In
the pop-up message box, click Yes to finish the deletion.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
