DS-1100KI Network Keyboard User Manual
19
STRONG PASSWORD RECOMMENDED–We highly recommend that you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters,
numbers, and special characters) in order to increase the security of your product. We recommend that
you reset your password regularly, especially in the high security system, resetting the password monthly
or weekly can better protect your product.
Figure 2. 12 Admin Main Interface
4. Click Keyboard > Network to enter the Network Settings interface.
Configure the network settings of the keyboard, including the Port, IP address, Subnet Mask, Default
Gateway, Preferred DNS and Alternate DNS. Click Apply to save the settings.
Figure 2. 13 Network Settings
5. Click Return to back to the main interface.
6. Click Device on the admin main interface to enter the device management menu.
7. Click Add Device to enter the Device-Add Device interface. Input the device name, device IP/domain name,
port, user name and password, and then click Add to add the device.
STRONG PASSWORD RECOMMENDED

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
