HIKVISION DS-1100KI User Manual

DS-1100KI Network Keyboard User Manual
36
Figure 3. 26 Adding Device
3. The successfully added device is listed on the User-Device interface.
Figure 3. 27 Device List
4. After having configured the above settings, click Logout on the admin main interface, the message box
“Logout now?” pops up. Click Yes to confirm the logout, or No to cancel the operation.
Deleting a Device
Enter the User-Device interface, you can select the device from the list and click to delete the related device
for the current user. In the pop-up message box, click Yes to confirm the deletion.
Operator User Login
On the User-User List interface, you can click (Login Operator) to directly switch to the Operator user login
interface.
Figure 3. 28 Loging in Operator Interface

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
